Productdetails:
|
|
| Plaats van herkomst: | China |
|---|---|
| Merknaam: | Glawall |
| Certificering: | SGS, ISO 9001,UL, CE |
| Modelnummer: | Volledig modulair dubbelglaswand |
| Document: | 25mm.pdf |
|
Betalen & Verzenden Algemene voorwaarden:
|
|
| Min. bestelaantal: | 10 vierkante Maters |
| Prijs: | US$80.00 10 - 99 square meters |
| Verpakking Details: | Multiplex |
| Levertijd: | 20-25 dagen |
| Betalingscondities: | L/C, D/A, D/P, T/T, Western Union |
| Levering vermogen: | 3000 vierkante meter per maand |
|
Gedetailleerde informatie |
|||
| Voordeel: | Concurrerende prijs, goede service, hoge professionaliteit, kwaliteitsgarantie | Plaats van origi: | Guangdong, China |
|---|---|---|---|
| Fabriekscertificering: | Ja | Fabrieksgebied: | 20000 vierkante meter |
| Materiaal: | Aluminiumframe, akoestische panelen | Klankbeveiliging: | 38-45db |
| Paneeldikte: | 60, 90,108 mm | Glazen: | sterk gehard glas |
| Ventilatie: | Airflow systeem | Garantie: | 2 jaar |
| Markeren: | 90mm aluminum partition wall,double glass modular partition,aluminum frame partition system |
||
Productomschrijving
| Advantage | Competitive price, good service, high professional, quality guarantee |
| Place of Origin | Guangdong, China |
| Factory Certification | Yes |
| Factory Area | 20000 square meter |
| Material | Aluminum Frame, Acoustic Panels |
| Soundproofing | 38-45dB |
| Panel Thickness | 60, 90, 108mm |
| Glass Type | Strong tempered glass |
| Ventilation | Airflow System |
| Warranty | 2 Years |
| Feature | Benefit |
|---|---|
| Pre-Assembled Double Glass Panels | Complete 5+5mm glass panels with integrated frame - no on-site assembly |
| Plug-and-Play Channels | Simple installation with top/side/bottom aluminum tracks |
| Tool-Free Connection | Patented click-lock system secures panels without tools |
| Fast Installation | 2-person team can install 20m² in under 3 hours |
| 42dB Soundproof Rating | 10mm air gap effectively blocks office noise |
| Thermal Insulation | Reduces HVAC costs by maintaining stable temperatures |
| Step | Action |
|---|---|
| Step 1 | Install aluminum tracks (ceiling/floor/sides) using laser level |
| Step 2 | Slide pre-assembled glass units into steel keel - no heavy lifting required |
| Step 3 | Snap decorative covers over joints for perfect alignment |
| Feature | Specification |
|---|---|
| Frame | 90mm powder-coated aluminum (20+ RAL colors) |
| Glass | 5+5mm tempered (clear/frosted/tinted options) |
| Acoustics | 42dB Rw (upgradable to 48dB with laminate) |
| Fire Rating | EI30-EI60 available |
| Max Height | 4m without additional support |
| For Contractors | For Clients |
|---|---|
| 70% faster installs = more projects per year | Immediate usability - No waiting for paint/drywall to cure |
| 50% less labor cost vs traditional systems | Adaptable layouts - Reconfigure teams without construction |
| No construction waste - LEED points achievable | Premium aesthetics - Sleek, modern appearance |
